SMedia SA is a Swiss company specializing in the design and distribution of projection screens.
We believe that we have one of the most complete and cost effective range of projection screens available on the market.
Our ranges of tripod, manual and electric wall screens are manufactured to ISO9001-2000 standards and fully comply with EU safety standards.
Typical applications of our products are found in schools, universities, technical colleges, conference and meeting rooms, executive facilities and training centres. We have also produced a special range of screens for government tenders to support distributors bids . Private users enjoy SMedia products in their Home Theatres.
SMedia screens are available EU customs cleared. Stock items are deliverable within 2-3 business days from our Amsterdam warehouse.
Apollo-T
Portable screen on a tripod
Advantages.
• The strength and stability of the tripod for screens up to 200cm.
• Telescopic stand, lights the upper position to select the size and height of the projection.
• Proof trapeze to compensate for image distortion with three options position.
• Black body and a black strap to improve the perception of image brightness.
• Flat and smooth screen surface.
• No seams on the projection surface.
Features and specifications
• The octagonal building screen is compact, is made of steel with a white polymer coating and high-impact white plastic.
• The telescopic rack is made of steel pipe with a black coated 20 mm and 25 mm.
• Supports tripod of bent steel profiles with a black polymer coating are soft plastic tips.
• Material fabric display environmentally safe, fully satisfy the requirements of fire safety on building materials and ingredients.
Reflection characteristics
Fabrics MW: the reflection coefficient of 1.0, viewing angle of 140 degrees.
Format Screen Size (cm) Viewing area size (cm) Diagonal (cm) Fabrics
__________________________________________________________________________
150X150 150X150 212 MW
1:1 180X180 180X180 255 MW
200X200 200X200 283 MW
__________________________________________________________________________
APOLLO
Portable screen on a tripod.
Advantages
• The strength and stability of the tripod for screens up to 250cm.
• Comfortable balanced handle for carrying.
• Telescopic stand, lights the upper position to select the format projection.
• Fixing the holes and push-button controls for ease and speed of folding and unfolding.
• Proof trapeze to compensate for image distortion with three options position.
• Ability to easily detach the tripod on the shell screen.
• Black bezel for all screens to improve the perception of the image brightness.
• Flat and smooth screen surface.
• No seams on the projection surface.
Features and specifications
• The octagonal building screen is compact, is made of steel with a white polymer coating and high-impact white plastic.
• The telescopic rack is made of chrome steel square profile of 20 mm and 25 mm.
• Supports the tripod of bent steel profiles with a white polymer coating are soft plastic tips.
• Material fabric display environmentally safe, fully satisfy the requirements of fire safety on building materials and ingredients.
Reflective characteristics
Fabrics MW: the reflection coefficient of 1.0, viewing angle of 140 degrees.
Format Screen Size (cm) Viewing area size (cm) Diagonal (cm) Fabrics
_________________________________________________________________________________
127X127 121X121 171 MW
153X153 147X147 208 MW
180X180 172X172 243 MW
1:1 203X203 195X195 276 MW
213X213 205X205 290 MW
244X244 236X236 334 MW
_________________________________________________________________________________
153X114 147X108 182 MW
171X128 165X122 205 MW
4:3 203X153 195X145 243 MW
244X183 236X175 294 MW
Economy-P
Economy wall screen for educational institutions.
Advantages
• Economical, compact, classic design.
• Fixing mechanism for selecting the right format projection.
• Wall and ceiling mount.
• Black body and a black strap to improve the perception of image brightness.
• Smooth smooth surface of the screen.
• No seams on the projection surface for all sizes of the model.
Features and specifications
• The octagonal building screen is made of steel with a black polymer coating and high-impact plastic.
• Lower Tension steel strap round cross-section of 20 mm diameter with a black polymer coating
• Material fabric display environmentally safe, fully satisfy the requirements of fire safety on building materials and ingredients.
Reflectio characteristics
Fabrics MW: the reflection coefficient of 1.0, viewing angle of 140 degrees.
Economy
Economy wall screen for educational institutions
Advantages
• Economical, compact, classic design.
• Fixing mechanism to select the desired size and height of the projection.
• Wall and ceiling mount.
• The presence of black svetopoglaschayuschey wide rim (68 cm to 90 cm, proportional to the size of the screen) in a 16:9 to set the desired height of projection.
• The black bezel all screens in order to improve the perception of image brightness
• Smooth smooth surface of the screen.
• No seams on the projection surface for all sizes of the model.
Features and specifications
• Quality Management System screens international standards ISO9001-2000.
• Building a square screen is made of steel with a white polymer coating and high-impact plastic.
• The lower adjuster strap steel circular section with a diameter of 20 mm with white coated
• Material fabric display environmentally safe, fully satisfy the requirements of fire safety on building materials and ingredients.
Reflective characteristics
Blades MW: the reflection coefficient of 1.0, viewing angle of 140 degrees.
Fabrics GB: reflection coefficient 2.8, viewing angle of 70 degrees.
Format Screen Size (cm) Viewing area size (cm) Diagonal (cm) Fabrics
_________________________________________________________________________________
127X127 121X121 171 MW
153X153 147X147 208 MW
165X165 159X159 225 MW
1:1 180X180 172X172 243 MW
203X203 195X195 276 MW
_________________________________________________________________________________
153X114 147X108 182 MW
4:3 171X128 165X122 205 MW
203X153 195X145 243 MW
_________________________________________________________________________________
153X153 147X82.5 169 MW
16:9 171X171 165X92.5 189 MW
203X203 195X109.5 224 MW
GOLDVIEW
Wall screen for different rooms.
Advantages.
Large assortment of sizes, heights from 127 cm to 305 cm
Fixing mechanism to select the desired size and height of the projection.
Wall and ceiling mount.
The presence of black svetopoglaschayuschey wide rim (from 67 cm to 132 cm, the proportional size of the screen) in a 16:9 to set the desired height of projection.
The black bezel all screens to improve the perception of image brightness
Smooth smooth surface of the screen.
No seams on the projection surface for all sizes models.
Features and specifications
Quality Management System screens international standards ISO9001-2000.
Building a square screen is made of steel with a white polymer coating and high-impact plastic.
Lower adjuster strap steel circular cross section 20 mm in diameter with a white polymer coating.
Materials cloth screen environmentally safe, fully satisfy the requirements of fire safety to building materials and components.
Reflective characteristics
Blades MW: the reflection coefficient of 1.0, viewing angle of 140 degrees.
Fabrics GB: reflection coefficient 2.8, viewing angle of 70 degrees.
Format Screen Size (cm) Viewing area size (cm) Diagonal (cm) Fabrics
______________________________________________________________________________________
1:1 127X127 121X121 171 MW, HCG, GB
153X153 147X147 208 MW, HCG, GB
180X180 172X172 243 MW, HCG, GB
203X203 195X195 276 MW, HCG, GB
213X213 205X205 290 MW, HCG, GB
244X244 236X236 334 MW, HCG, GB
274X274 266X266 376 MW, HCG, GB
305X305 297X297 420 MW, HCG, GB
_______________________________________________________________________________________
4:3 153X114 147X108 182 MW, HCG, GB
171X128 165X122 205 MW, HCG, GB
203X153 195X145 243 MW, HCG, GB
244X183 236X175 294 MW, HCG, GB
274X206 266X198 332 MW, HCG, GB
305X229 297X221 370 MW, HCG, GB
366X274 358X266 446 MW, HCG, GB
406X305 394X293 491 MW, HCG, GB
________________________________________________________________________________________
16:9 153X153 147X82.5 169 MW, HCG, GB
171X171 165X92.5 189 MW, HCG, GB
203X203 195X109.5 224 MW, HCG, GB
244X244 236X132.5 271 MW, HCG, GB
274X274 266X149.5 305 MW, HCG, GB
305X305 297X167 341 MW, HCG, GB
CHAMPION
Economy Electric screen for different rooms.
Advantages
• Large assortment of sizes, height from 114 cm to 305 cm
• The presence of black svetopoglaschayuschey wide rim (from 67 cm to 132 cm, the proportional size of the screen) in a 16:9 to set the desired height of the projections.
• Black bezel for all screens to improve the perception of the image brightness.
• The body is fully hide when minimized bottom bar.
• Quiet electric motor optimal power does not require maintenance lifetime.
• Increased durability and ease of use provides an automatic stop when deploying and coagulation.
• Easy replacement of the switch, which is included in basic equipment, wireless device (infrared or radio frequency).
• Wall and ceiling installation.
• Smooth smooth surface of the screen.
• No seams on the projection surface for all sizes of the model.
Features and specifications
• Quality Management System screens international standards ISO9001-2000.
• Screen meets stringent European standards for quality and safety and has the CE certificate.
• Cable length 5m. Cable equipped with a switch to control the screen.
• Electric power 18Vt/36Vt (for wide screens of up to 240 cm / over 240 cm), engine speed 1915 rpm.
• The body with a square screen is made of steel with a white coating. End caps shells are made from high-impact white plastic.
• Lower Tension steel strap round cross-section diameter of 13mm with a black coating.
• Materials cloth screen environmentally safe, fully satisfy the requirements of fire safety to building materials and components.
Reflective characteristics
Blades MW: the reflection coefficient of 1.0, viewing angle of 140 degrees.
Fabrics HCG: the reflection coefficient 0.9, viewing angle 140 degrees.
Fabrics GB: reflection coefficient 2.8, viewing angle of 70 degrees.
Format Screen Size (cm) Viewing area size (cm) Diagonal (cm) Fabrics
__________________________________________________________________________________
1:1 127X127 121X121 171 MW, HCG, GB
153X153 147X147 208 MW, HCG, GB
180X180 172X172 243 MW, HCG, GB
203X203 195X195 276 MW, HCG, GB
213X213 205X205 290 MW, HCG, GB
244X244 236X236 334 MW, HCG, GB
274X274 266X266 376 MW, HCG, GB
305X305 297X297 420 MW, HCG, GB
__________________________________________________________________________________
4:3 153X114 147X108 182 MW, HCG, GB
171X128 165X122 205 MW, HCG, GB
203X153 195X145 243 MW, HCG, GB
244X183 236X175 294 MW, HCG, GB
274X206 266X198 332 MW, HCG, GB
305X229 297X221 370 MW, HCG, GB
366X274 358X266 446 MW, HCG, GB
406X305 394X293 491 MW, HCG, GB
__________________________________________________________________________________
16:9 153X153 147X82.5 169 MW, HCG, GB
171X171 165X92.5 189 MW, HCG, GB
203X203 195X109.5 224 MW, HCG, GB
244X244 236X132.5 271 MW, HCG, GB
274X274 266X149.5 305 MW, HCG, GB
305X305 297X167 341 MW, HCG, GB
How to choose a Projection Screen
Whether you are setting up a home theatre system, using your screen with a computer for business meetings or even in a stadium environment, there are certain things to take into account when purchasing a projection screen which can affect the efficiency of the product as well as the reliability of the product. But do not be afraid, choosing the right screen is very EASY!
Instructions
1.
First determine if you need a front projection or a rear projection screen based on your projector and space requirements.
2.
The screen surface affects the brightness and sharpness of the projected images. Lighting and intent of use are the most important factors.
Gain – Viewing Angle
The screens gain has to do with how much light is emitted from the screen when projected upon. A high gain will allow you to keep the lights on without sacrificing the ability to see the images on the screen. Gain is in reversely related to the of the viewing angle, so a high gain reduces your ability to see the screen from the sides of a room.
Matte White (MW)Matte White (MW) finishes, (available on all Screen Models series Apollo-T, Apollo, Economy-P, Economy, Goldview and Champion) the most common, provide good definition for text and color slides (best for use with computer applications).
PS Matte White (PS MW) finishes (series Super Mobile, Fantasy-M, Cyber-M and PermFix ) is used for Tension system screens. This new elastic surface is with microscopic spherical diamond inclusions which increase reflection and provide the perfect brightness of colors.
High Contrast Grey (HCG) finishes (available for series Goldview and Champion) are ideal for movies or other video applications and are intended for rooms with side lighting such as living rooms. This surface in grey color makes the picture more contrast.
PS High Contrast Grey (PS HCG) is available for Tension system screens. ( available for series Fantasy-M, Cyber-M, PermFix and Excluzive )
Glass beaded (GB) finishes are made using new technology: titanium and barium are used instead of lead. This surface provides very contrast picture with deep black color. ( Goldview series )
PS Cineflex surfaces are using for rear projection screens (series PermFix and Easy-com). This surface has neutral grey color and provides high resolution and contrast of images. Available for Tension system screens.
3
. The flatness of the screen can be more or less important based on your application, so when purchasing a screen a tensioning system (series Fantasy-M, Cyber-M, PermFix and Excluzive) may prove to be useful.
4.
Black borders (all series except Apollo-T and Economy-P) can be very helpful. They will provide a boundary around the edges of the projected image providing a cleaner, more professional look.
5.
Motorized screens (series Champion, Elegant, Fantasy-M, Cyber-M Excluzive and SkyShow), will give you the comfort of rolling the screen out at the push of a button. This command can be performed by wireless remote control (SMRF-01 RF Remote Control and SMIR-01 IR Remote Control) or by wired remote control which is included in the standard package.
How to Pick the Right Size Projector Screen
Determining the best screen size for your video projector requires some research. The wrong projector screen size can distort your images and an over-sized screen will cause you to move your head and eyes constantly, as if watching a tennis match. As a rule of thumb, choosing the right projection screen size should depend on your audience rather than the projector, and it is mostly a matter of personal preference. But don’t be afraid! It is VERY EASY!!!
Instructions
Things You will Need:
Black electrical tape
Video projector
Tape measure
1
Imagine how big you want the screen to be. Using black electrical tape, mark the imaginary corners of your future screen. Professionals recommend a screen size of 100 inches (2.54 meters) diagonally for basic home theaters. Place your seat in front of the large rectangle at your preferred distance, adjusting until you find the comfortable size and distance from your seating.
2
Determine the native resolution or native aspect ratio of your projector. Most projectors have 16:9 (standard wide screen, HDTV) and 4:3 (classic) ratios.
3
Look at the ceiling height of your room. Ideally, a screen should be at least 30 cm from the ceiling and 90cm to 120cm above the floor.
4
Consider the distance the audience will be sitting from the screen. The most comfortable viewing distance should be 1.5 times the width of the screen.
Tips & Warnings
Important considerations in choosing the right screen include the screen's tension and retraction mechanism.
A small screen might make text hard to read.
A screen that is too large is hard on the eyes and may cause "tennis neck."
If you will use the screen primarily to watch sports or play video games, go for a gray screen. These create better images in rooms with sufficient light.
If you watch movies often, the room in which you install the screen should have less or adjustable lighting. Additionally, white screens are better for movie watching because they better show vibrant colors.
High-gain screens don't necessarily produce the best appearance and can cause "hot spotting" in which the screen appears brighter than the edges.
Consult with experts in screen technology who can indicate which types of screen works best for a particular projector model.
SMedia SA
Tel.: +41 26 475 50 60
Rue St-Pierre 18, 1700 Fribourg
SWITZERLAND
sales@s-media.ch
We are pleased to announce that SMedia is starting to distribute and sell probably the best price/performance projection screens in Europe.
Almost any business today needs a projection screen, any educational institution has also a screen in the classroom. A bar without a large screen is not considered a bar any more. The number of Home Movie Theaters is showing an exponential growth. So, a projection screen is becoming a consumable product, something that we see almost every day.
If you are a dealer, we are giving you the opportunity to join a successful team of young entrepreneurs who have seen a great potential in European projection screen market. Our prices are excellent, goods are EU customs cleared, centrally located in Europe, in the beautiful city of Amsterdam.
Being an SMedia dealer is a rewarding experience. If you qualify, you will be a part of a great network of AV professionals active throughout Europe with whom you can exchange experiences, show new products and offer your overstock items.
You may even have a chance to have your DEMO order shipped free of charge and delivered to you within 3 business days. Please call for details!
We do not sell direct to the end-user nor do we sell on the internet. But YOU are welcome to do it!
Give us call or send us an e-mail! Share your future with SMedia!
Your SMedia team
